Ra'ayin 800m 850nm Lite Infrared Meduke Laser
|
Abin ƙwatanci |
Sg - Ir850 - 8ml |
|
Ingancin nesa |
≥800m |
|
Dabara |
VCSEL |
|
Igiyar ruwa |
850 ± 10nm |
|
Yarjejeniyar Laser |
Class 3B |
|
Inputer Power |
<20.0w |
|
Laser guntu Power |
4.4 ± 0.3W |
|
Powerarfin Wuta |
4.0 ± 0.3W |
|
Kusurwar Laser |
38 °, nesa mai tasiri> 800m, Baske tabo diamita |
|
Kusa da kusurwa 71 °, nesa mai tasiri> 80m |
|
|
Zuƙo sauri |
≤ 3s (nesa nesa ~ kusa kusurwa) |
|
Yanayin sarrafawa |
UART_TTL, Rs - 485, Manual |
|
Kuntawa |
Rs - 485, TTL232, Gudanar da Manufar |
|
Protecol Sadarwa |
Pelco - D (9600bps tsoho, 115200bps, 4800bps, 2400bps don zaɓi) |
|
Yanayin aiki |
Ci gaba |
|
Rayuwar Ma'aikata |
≥ 50000h |
|
Inputer Power |
DC12V ± 10% |
|
Aiki na yanzu |
<1.65a |
|
Yawan zafin jiki |
- 40 ° C ~ 70 ° C |
|
Zazzabi mai ajiya |
- 40 ° C ~ + 80 ° C |
|
Gwadawa |
66mm * 35m * 47mm |
|
Nauyi |
Kimanin. 105g |
